PLAN 70-852
Cost to Build Reports Only $9.99 with Code CTB2022 (Limit 1)
This report will provide you cost estimates based on location and building materials.
Get Personalized Help
Phone: 1-888-447-1946
See our Terms & Conditions and Privacy Policy.
PLAN 70-852
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Height : 31'
Width : 113' 4"
First Floor: 4190 sq/ft
Garage: 947 sq/ft
Roof Framing : Truss
Roof Type : Shingle
Secondary Pitch : 12:12
Framing : 2"x6"
Split Bedrooms
Walk In Closet
Kitchen Island
Walk In Pantry Cabinet Pantry
Great Room Living Room
Hobby Rec Room Game Room
Media Room
Storage Area
Side Entry Garage
Suited For View Lot
Basement Foundation:
9973 sq/ft width 113' 4" x depth 88'
Bathroom 2:
64 sq/ft width 10' 4" x depth 6' 3"
Bathroom 3:
57 sq/ft width 5' x depth 11' 7"
Bathroom 4:
67 sq/ft width 13' 6" x depth 5'
Bedroom 2:
220 sq/ft width 14' 8" x depth 15'
Bedroom 2 Closet:
32 sq/ft width 6' 6" x depth 5'
Bedroom 3:
194 sq/ft width 16' 8" x depth 11' 8"
Bedroom 3 Closet:
42 sq/ft width 5' x depth 8' 7"
Bedroom 4:
317 sq/ft width 18' 8" x depth 17'
Bedroom 4 Closet:
27 sq/ft width 13' 6" x depth 2'
Breakfast Room:
170 sq/ft width 17' x depth 10'
Den:
227 sq/ft width 13' x depth 17' 6"
Dining Room:
265 sq/ft width 15' x depth 17' 8"
Foyer:
107 sq/ft width 8' 3" x depth 13'
Game Room:
595 sq/ft width 25' 4" x depth 23' 6"
Garage:
979 sq/ft width 23' 6" x depth 41' 8"
Gathering Room:
414 sq/ft width 18' x depth 23'
Hall:
94 sq/ft width 4' x depth 23' 7"
Hall Bathroom:
65 sq/ft width 6' 8" x depth 9' 9"
Hall Closet:
14 sq/ft width 2' x depth 7' 4"
Hearth Room:
204 sq/ft width 17' x depth 12'
Kitchen:
221 sq/ft width 17' x depth 13'
Laundry Room:
126 sq/ft width 14' x depth 9'
Master Bathroom:
292 sq/ft width 18' 8" x depth 15' 8"
Master Bedroom:
330 sq/ft width 16' x depth 20' 8"
Master Closet:
214 sq/ft width 14' 4" x depth 15'
Media Room:
335 sq/ft width 19' x depth 17' 8"
Pantry:
45 sq/ft width 8' 6" x depth 5' 4"
Patio:
667 sq/ft width 29' x depth 23'
Porch - Front:
53 sq/ft width 7' 8" x depth 7'
Powder Room:
26 sq/ft width 5' 4" x depth 5'
Storage:
1266 sq/ft width 33' 4" x depth 38'
Storage Closet:
774 sq/ft width 28' x depth 27' 8"
Wet Bar:
83 sq/ft width 8' 8" x depth 9' 8"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
| 5 Copy Set : $2221.90 |
5 printed plan sets mailed to you. |
| 8 Copy Set : $2327.30 |
8 printed plan sets mailed to you. |
| PDF Set : $2909.55 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| Reproducible Set : $2909.55 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
| CAD Set : $4654.60 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
| Daylight Basement: $0.00 |
Ideal for sloping lot, lower level of home partially underground. |
| Crawlspace: $284.75 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
| Slab: $284.75 |
Ideal for level lot, single layer concrete poured directly on grade. |
Additional Options
| Right-Reading Reverse : $250.75 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Additional Construction Sets : $42.50 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $85.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $33.15 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Mirror Reversed Sets : $34.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
