PLAN 70-1154
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 82'
Height : 30'
Width : 94'
Area
Basement Living: 2966 sq/ft
First Floor: 3394 sq/ft
Ceiling
Ceiling Details : Barrel Vault Foyer, 11' Step MBR. & Sit. Rm., 16' Coffered Grt. Rm., 16' Wood Beam Hrth. & Kit., 11'-6" Step Din., 13' Sun., Dome Staircase
Main Ceiling : 10'
Roof
Primary Pitch : 12:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Stone
Framing : 2x6
Bedroom Features
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Great Room Living Room
Hobby Rec Room Game Room
Master Sitting Area
Storage Area
Sunroom
Wet Bar
Garage Features
Side Entry Garage
Split Garage
Lot Characteristics
Suited For View Lot
Outdoor Spaces
Screened Porch
More
Jack & Jill Bath
Rooms
3rd BR Closet:
16 sq/ft width 8' x depth 2'
Bathroom 2:
60 sq/ft width 10' 8" x depth 5' 8"
Bathroom 3:
72 sq/ft width 5' 2" x depth 14'
Bedroom 2:
229 sq/ft width 15' 4" x depth 15'
Bedroom 2 Closet:
12 sq/ft width 2' x depth 6' 4"
Bedroom 3:
147 sq/ft width 12' 8" x depth 11' 8"
Bedroom 3 Closet:
12 sq/ft width 2' x depth 6' 4"
Bedroom 4:
176 sq/ft width 11' 6" x depth 15' 4"
Bedroom 4 Closet:
29 sq/ft width 5' 8" x depth 5' 2"
Breakfast Room:
283 sq/ft width 14' 8" x depth 19' 4"
Deck:
594 sq/ft width 22' x depth 27'
Dining Room:
238 sq/ft width 17' x depth 14'
Foyer:
128 sq/ft width 26' 6" x depth 4' 10"
Game Room:
212 sq/ft width 14' 6" x depth 14' 8"
Garage:
770 sq/ft width 25' 8" x depth 30'
Garage Two:
448 sq/ft width 16' x depth 28'
Gathering Room:
333 sq/ft width 18' x depth 18' 6"
Hall Bathroom:
38 sq/ft width 6' 8" x depth 5' 10"
Hall Closet:
10 sq/ft width 2' x depth 5'
Kitchen:
309 sq/ft width 16' x depth 19' 4"
Laundry Room:
50 sq/ft width 8' 2" x depth 6' 2"
Master Bathroom:
203 sq/ft width 14' 2" x depth 14' 4"
Master Bedroom:
241 sq/ft width 17' 8" x depth 13' 8"
Master Closet:
150 sq/ft width 12' x depth 12' 6"
Porch - Front:
41 sq/ft width 8' x depth 5' 2"
Powder Room:
50 sq/ft width 9' 10" x depth 5' 2"
Storage:
388 sq/ft width 14' 8" x depth 26' 6"
Sun Room:
336 sq/ft width 18' 4" x depth 18' 4"
Theatre Room:
212 sq/ft width 14' 6" x depth 14' 8"
Utility Room:
75 sq/ft width 7' 10" x depth 9' 8"
Walk-In Closet:
30 sq/ft width 4' x depth 7' 6"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
Plan Set
$2862.00
$2990.00
$3689.00
$3689.00
$5915.00
Foundation
$0.00
$395.00
$395.00
Additional Options
$395.00
$80.00
$100.00
$495.00
$39.00
$75.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
