PLAN 17-3346
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Height : 51' 8"
Width : 156' 8"
First Floor: 4728 sq/ft height 12'
Garage: 2140 sq/ft
Second Floor: 1946 sq/ft height 10'
Framing : Wood - 2x4
Main Floor Master Bedroom
Family Room Keeping Room
Great Room Living Room
Loft
Main Floor Laundry
Media Room
Sunroom
Unfinished Future Space
Covered Rear Porch
Screened Porch
Bathroom 2:
128 sq/ft width 14' 10" x depth 8' 8"
Bathroom 3:
138 sq/ft width 16' x depth 8' 8"
Bedroom 2:
262 sq/ft width 13' 10" x depth 19'
Bedroom 3:
262 sq/ft width 13' 10" x depth 19'
Bedroom 4:
262 sq/ft width 13' 10" x depth 19'
Bonus Room - Finished:
355 sq/ft width 22' x depth 16' 2"
Breakfast Room:
266 sq/ft width 14' x depth 19'
Dining Room:
298 sq/ft width 13' 8" x depth 21' 10"
Garage:
684 sq/ft width 24' x depth 28' 6"
Garage Storage:
185 sq/ft width 9' 6" x depth 19' 6"
Garage Two:
552 sq/ft width 23' x depth 24'
Great Room:
622 sq/ft width 28' 6" x depth 21' 10"
Grilling Porch:
593 sq/ft width 29' 8" x depth 20'
Hearth Room:
411 sq/ft width 17' 6" x depth 23' 6"
Kitchen:
376 sq/ft width 21' 6" x depth 17' 6"
Laundry Room:
143 sq/ft width 14' 4" x depth 10'
Master Bathroom:
332 sq/ft width 18' 8" x depth 17' 10"
Master Closet:
175 sq/ft width 13' 8" x depth 12' 10"
Master Suite:
313 sq/ft width 19' x depth 16' 6"
Porch - Screened:
266 sq/ft width 19' x depth 14'
Port Cochere:
432 sq/ft width 18' x depth 24'
Storage:
63 sq/ft width 9' 4" x depth 6' 10"
Study:
298 sq/ft width 13' 8" x depth 21' 10"
Theatre Room:
585 sq/ft width 27' x depth 21' 8"
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
- Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
| PDF Set : $2850.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| 5 Copy Set : $2950.00 |
5 printed plan sets mailed to you. |
| 5 Copy and PDF Set : $3200.00 |
5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| CAD Set : $5700.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
| Crawlspace: $0.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
| Basement: $299.00 |
Ideal for level lot, lower level of home partially or fully underground. |
| Daylight Basement: $299.00 |
Ideal for sloping lot, lower level of home partially underground. |
Framing
| Wood 2x4: $0.00 |
Wood 2x4 |
| Wood 2x6: $299.00 |
Wood 2x6 |
Additional Options
| Right-Reading Reverse : $199.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Additional Construction Sets : $75.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design : $200.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
