Bedroom 2:
233 sq/ft width 13' 4" x depth 17' 6"
Bedroom 3:
206 sq/ft width 16' 6" x depth 12' 6"
Bedroom 4:
204 sq/ft width 13' 4" x depth 15' 4"
Bedroom 5:
242 sq/ft width 17' 4" x depth 14'
Breakfast Room:
195 sq/ft width 13' 6" x depth 14' 6"
Butler's Pantry:
50 sq/ft width 10' x depth 5'
Dining Room:
246 sq/ft width 17' x depth 14' 6"
Game Room:
315 sq/ft width 17' 6" x depth 18'
Gathering Room:
438 sq/ft width 19' 6" x depth 22' 6"
Kitchen:
293 sq/ft width 16' 4" x depth 18'
Living Room:
214 sq/ft width 14' 2" x depth 15' 2"
Master Bathroom:
714 sq/ft width 18' 4" x depth 39'
Master Bedroom:
389 sq/ft width 17' 4" x depth 22' 6"
Master Closet - Hers:
128 sq/ft width 12' x depth 10' 8"
Master Closet - His:
90 sq/ft width 9' 8" x depth 9' 4"
Pantry:
108 sq/ft width 10' 6" x depth 10' 4"
Study:
322 sq/ft width 22' 6" x depth 14' 4"
Utility Room:
120 sq/ft width 10' 6" x depth 11' 6"
All plans are drawn at ¼” scale or larger and include :
PDF Set : $1542.75 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Wood 2x4: $0.00 |
Wood 2x4 |
Additional Construction Sets : $51.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
Audio Video Design : $85.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
Construction Guide : $33.15 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
Material List : $72.25 |
A list of building supplies needed to construct the infrastructure of your new house. Please note materials lists will not reflect add-ons such as alternate foundation and framing options. |
Mirror Reversed Sets : $46.75 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
