PLAN 17-3282

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.

Modify This Plan

Full Specs & Features


Depth : 111' 7"

Height : 41' 2"

Width : 146' 5"


First Floor: 5492 sq/ft height 10'

Garage: 1072 sq/ft

Porch: 3812 sq/ft

Second Floor: 2992 sq/ft height 10'

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.


Primary Pitch : 8:12

Roof Framing : Conventional

Exterior Wall Framing

Framing : Wood - 2x4

Bedroom Features

Guest Suite

Main Floor Master Bedroom

Walk In Closet

Kitchen Features

Butler's Pantry

Kitchen Island

Kitchenette Wet Bar

Additional Room Features

Den Office Study Computer

Exercise Room

Great Room Living Room

Hobby Rec Room Game Room

Main Floor Laundry

Master Sitting Area

Media Room

Mud Room

Upstairs Laundry



Bathroom 2:

195 sq/ft width 12' 5" x depth 15' 9"

Bathroom 3:

184 sq/ft width 12' 5" x depth 14' 10"

Bedroom 2:

324 sq/ft width 19' 8" x depth 16' 6"

Bedroom 3:

324 sq/ft width 19' 8" x depth 16' 6"

Breakfast Area:

135 sq/ft width 9' x depth 15'

Dining Room:

324 sq/ft width 19' 8" x depth 16' 6"

Exercise Room:

285 sq/ft width 17' 10" x depth 16'


443 sq/ft width 22' 2" x depth 20'

Game Room:

455 sq/ft width 22' 6" x depth 20' 3"


897 sq/ft width 23' x depth 39'

Garage Storage:

107 sq/ft width 10' 9" x depth 10'

Great Room:

450 sq/ft width 22' 6" x depth 20'

Guest Bathroom:

110 sq/ft width 12' x depth 9' 2"

Guest Bedroom:

432 sq/ft width 27' x depth 16'

Hearth Room:

467 sq/ft width 17' 4" x depth 27'

Home Theater:

282 sq/ft width 15' 8" x depth 18'


405 sq/ft width 19' x depth 21' 4"

Laundry Room:

197 sq/ft width 16' 8" x depth 11' 10"

Master Bathroom:

310 sq/ft width 15' 6" x depth 20'

Master Bedroom:

336 sq/ft width 23' 6" x depth 14' 4"

Master Closet - Hers:

168 sq/ft width 9' 9" x depth 17' 4"

Master Closet - His:

161 sq/ft width 16' 9" x depth 9' 8"

Master Sitting Area:

2013 sq/ft width 17' 4" x depth 116' 2"

Powder Room:

52 sq/ft width 9' x depth 5' 10"

Sewing Room:

245 sq/ft width 17' 6" x depth 14'


324 sq/ft width 19' 8" x depth 16' 6"

What's Included In This Plan Set

  • Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost. (walk out is not shown on elevations unless finished walk out)
  • Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
  • Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
  • Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. ** (cut throughs where applicable)
  • Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
  • Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
