Full Specs & Features
Depth : 36'
Height : 23'
Width : 24'
First Floor: 688 sq/ft
Second Floor: 374 sq/ft
Primary Pitch : 12:12
Roof Framing : Conventional
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x6
Additional Room Features
Main Floor Laundry
Vaulted / Cathedral Ceilings
Covered Front Porch
Covered Rear Porch
Wrap Around Porch
width 10' 10" x depth 11' 10"
Covered Rear Porch:
96 sq/ft width 24' x depth 4'
Covered Side Porch:
144 sq/ft width 4' x depth 36'
width 11' 6" x depth 5' 6"
width 15' 10" x depth 13' 8"
374 sq/ft width 15' x depth 21'
192 sq/ft width 24' x depth 8'
What's Included In This Plan Set
- Cover sheet with rendering and art floor plans
- General notes and specifications
- Site plan at 1/8″=1′-0″ or 1/4″= 1′-0″
- Foundation plan at 1/4″=1′-0″
- Main floor plan at 1/4″=1′-0″
- Second floor plan at 1/4″=1′-0″, if applicable
- Structural floor / roof information indicated either on the floor plans or separate framing plans for complicated designs
- Electrical floor plans
- Minimum of two cross sections at 1/4″=1′-0″
- Details as required
- All four elevations at 1/4″=1′-0″
- Generic detail sheet
- Plans are engineered by a structural engineer, but not stamped or sealed
- Ground snow load 40 psf. (or composite roof live load 32 psf, dead load 10 psf for total roof design load 42 psf)Floor live load 40 psf
- Balcony live load 60 psf and dead load 10 psf for total design load of 70 psf
- Assumed soil bearing capacity 1560 psf
- Electrical fixtures / switches / smoke alarms by location only on floor plans
- Plumbing fixtures by location only on floor plans
- Windows are called out as generic nominal sizes on floor plans, opening directions indicated on elevations
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
