PLAN 72-1027
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 28'
Height : 18'
Width : 72'
Area
First Floor: 1492 sq/ft height 8'
Roof
Primary Pitch : 6:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Living Room / Parlor
Main Floor Master Bedroom
Additional Room Features
Main Floor Laundry
Storage Area
Outdoor Spaces
Covered Front Porch
Deck
Rooms
3rd BR Closet:
9 sq/ft width 2' 1" x depth 4' 6"
Basement Foundation:
1456 sq/ft width 52' x depth 28'
Bathroom 2:
62 sq/ft width 5' x depth 12' 6"
Bedroom 2:
132 sq/ft width 12' x depth 11'
Bedroom 2 Closet:
9 sq/ft width 2' 1" x depth 4' 6"
Bedroom 3:
132 sq/ft width 12' x depth 11'
Bedroom 3 Closet:
9 sq/ft width 2' 1" x depth 4' 6"
Foyer:
38 sq/ft width 6' 10" x depth 5' 8"
Garage:
440 sq/ft width 20' x depth 22'
Hall:
58 sq/ft width 3' 1" x depth 19'
Hall Closet:
6 sq/ft width 2' 1" x depth 3' 2"
Kitchen:
350 sq/ft width 28' x depth 12' 6"
Laundry Room:
15 sq/ft width 3' 1" x depth 5'
Living Room:
187 sq/ft width 17' x depth 11'
Master Bathroom:
45 sq/ft width 5' x depth 9' 1"
Master Bedroom:
150 sq/ft width 12' x depth 12' 6"
Master Closet:
26 sq/ft width 3' 1" x depth 8' 7"
Porch - Front:
width 0" x depth 39' 2"
Slab Foundation:
235 sq/ft width 6' x depth 39' 2"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$831.60
$950.40
$1069.20
Foundation
$0.00
$247.50
$247.50
$247.50
Framing
$0.00
Additional Options
$175.50
$54.00
$445.50
$135.00
$445.50
$35.10
$135.00
$76.50
$0.00
$895.50
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
