PLAN 42-364
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 61'
Height : 23'
Width : 57'
Area
Bonus: 327 sq/ft
First Floor: 1865 sq/ft height 8'
Ceiling
Main Ceiling : 8'
Roof
Primary Pitch : 8:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : 2"x4"
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Additional Room Features
Great Room Living Room
Play Flex Room
Storage Area
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Wrap Around Porch
Rooms
Bedroom 2:
132 sq/ft width 11' x depth 12'
Bedroom 2 Closet:
17 sq/ft width 3' 4" x depth 5' 2"
Bedroom 3:
132 sq/ft width 11' x depth 12'
Bedroom 3 Closet:
17 sq/ft width 3' 4" x depth 5' 2"
Bonus Room - Unfinished:
273 sq/ft width 13' x depth 21'
Dining Room:
156 sq/ft width 12' x depth 13'
Garage:
441 sq/ft width 21' x depth 21'
Garage Storage:
44 sq/ft width 5' 6" x depth 8'
Gathering Room:
380 sq/ft width 19' x depth 20'
Hall:
37 sq/ft width 3' 4" x depth 11' 4"
Hall Bathroom:
62 sq/ft width 5' x depth 12' 6"
Hall Closet:
6 sq/ft width 2' x depth 3' 4"
Kitchen:
143 sq/ft width 11' 6" x depth 12' 6"
Laundry Room:
46 sq/ft width 5' 2" x depth 9'
Master Bathroom:
181 sq/ft width 11' x depth 16' 6"
Master Bedroom:
240 sq/ft width 15' x depth 16'
Master Closet:
28 sq/ft width 5' 4" x depth 5' 4"
Master Closet Two:
49 sq/ft width 5' 4" x depth 9' 4"
Porch - Front:
211 sq/ft width 6' x depth 35' 4"
Porch - Rear:
184 sq/ft width 10' 10" x depth 17'
Porch - Right:
114 sq/ft width 6' x depth 19'
