3rd BR Closet:
8 sq/ft width 4' 5" x depth 2'
Bathroom 2:
38 sq/ft width 7' 8" x depth 5'
Bedroom 2:
121 sq/ft width 11' x depth 11'
Bedroom 2 Closet:
16 sq/ft width 8' 3" x depth 2'
Bedroom 3:
115 sq/ft width 10' x depth 11' 6"
Bedroom 3 Closet:
16 sq/ft width 8' 3" x depth 2'
Breakfast Room:
98 sq/ft width 12' x depth 8' 2"
Dining Room:
138 sq/ft width 12' x depth 11' 6"
Foyer:
33 sq/ft width 4' x depth 8' 3"
Gathering Room:
281 sq/ft width 14' x depth 20' 1"
Hall Closet:
5 sq/ft width 2' 6" x depth 2'
Kitchen:
147 sq/ft width 12' 4" x depth 12'
Master Bathroom:
126 sq/ft width 12' x depth 10' 7"
Master Bedroom:
266 sq/ft width 18' 6" x depth 14' 5"
Master Closet:
54 sq/ft width 7' 8" x depth 7' 1"
Porch - Front:
90 sq/ft width 4' 6" x depth 20' 1"
Powder Room:
14 sq/ft width 5' 10" x depth 2' 6"
Storage:
59 sq/ft width 5' 7" x depth 10' 7"
Utility Room:
30 sq/ft width 5' 7" x depth 5' 6"
Walk-In Closet:
13 sq/ft width 4' x depth 3' 3"
5 Copy Set : $850.00 |
5 printed plan sets mailed to you. |
8 Copy Set : $1105.00 |
8 printed plan sets mailed to you. |
PDF Set : $1105.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
Reproducible Set : $1105.00 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
CAD Set : $1742.50 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Single Set : $680.00 |
One printed set for bidding purposes only. Not a legal building set for construction. |
Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Wood 2x4: $0.00 |
Wood 2x4 |
Additional Construction Sets : $106.25 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
Audio Video Design : $85.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
Construction Guide : $33.15 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
Lighting Design : $85.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
Mirror Reversed Sets : $0.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
