PLAN 48-553
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Dimension
Depth : 56'
Height : 27'
Width : 48'
Height : 27'
Width : 48'
Area
First Floor: 1675 sq/ft height 9'
Second Floor: 614 sq/ft
Second Floor: 614 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Shingle
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Shingle/Stone
Framing : Wood - 2x6
Framing : Wood - 2x6
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Upstairs Bedrooms
Walk In Closet
Main Floor Master Bedroom
Split Bedrooms
Upstairs Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Butler's Pantry
Eating Bar
Kitchen Island
Butler's Pantry
Eating Bar
Kitchen Island
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Great Room Living Room
Main Floor Laundry
Garage Features
Front Entry Garage
Lot Characteristics
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Rooms
3rd BR Closet:
18 sq/ft width 9' x depth 2'
Attic:
72 sq/ft width 9' x depth 8'
Bathroom 2:
88 sq/ft width 8' x depth 11'
Bedroom 2:
132 sq/ft width 11' x depth 12'
Bedroom 2 Closet:
10 sq/ft width 2' x depth 5'
Bedroom 3:
137 sq/ft width 11' 2" x depth 12' 4"
Bedroom 3 Closet:
10 sq/ft width 2' x depth 5'
Coat Closet:
24 sq/ft width 8' x depth 3'
Den/Office or Bedroom 1:
105 sq/ft width 10' x depth 10' 6"
Dining Room:
111 sq/ft width 11' x depth 10' 2"
Foyer:
101 sq/ft width 6' 9" x depth 15'
Garage:
399 sq/ft width 19' 6" x depth 20' 6"
Gathering Room:
272 sq/ft width 16' x depth 17'
Hall Bathroom:
27 sq/ft width 5' x depth 5' 6"
Kitchen:
187 sq/ft width 11' x depth 17'
Laundry Room:
55 sq/ft width 10' x depth 5' 6"
Linen Closet:
9 sq/ft width 3' x depth 3'
Master Bathroom:
130 sq/ft width 13' x depth 10'
Master Bedroom:
175 sq/ft width 15' x depth 11' 8"
Master Closet:
45 sq/ft width 9' x depth 5'
Porch - Front:
102 sq/ft width 17' x depth 6'
What's Included In This Plan Set
- Exterior Elevations
- In addition to the front exterior, your drawing set will include drawings of the rear and sides of your house as well. These drawings give notes on exterior materials and finishes. Particular attention is given to cornice detail, brick and stone accents, or other finish items that make your home unique.
-
Foundation Plan
- The foundation page dimensions, concrete walls, footings, pads, posts, beams, bearing walls, and any stepped foundation information along with any retaining wall info (schematic only). A typical wall section for the home is also usually included on this page (if not, it is elsewhere in your plan set, as space allows). If your plan features a poured concrete slab rather than a basement or crawlspace, the foundation page shows footings and details for the slab, and includes plumbing locations. If you choose the optional Slab foundation, the slab foundation will not be reflected in the plan sections.
-
Floor Plan(s)
- Exterior and interior wall framing, and windows/doors are dimensioned. Room sizes are indicated and any beams, posts and structural bearing points are called out. The floorplans include an electrical legend, and electrical fittings, lights and outlets are shown. Floor Plans will also indicate cross–section details (provided on the sections page) and show any special framing details applicable to the design. Cabinet elevations are included for kitchen and bathrooms; some designs feature cabinet elevations for design–related built–ins too.
-
Building Sections
- Building sections show changes in floor, ceiling, or roof height, and the relationship of one level to another. Our section pages also show how the stairs are calculated (if there are some!) and depict roof and foundation members. We try and draw sections to show the most useful information — choosing locations where there are elements you or your contractor might need clarification on.
-
Roof Plan
- Roof framing or truss directions are shown, slope directions are indicated and structural members are sized and called out if applicable. The gravity loads used to calculate the rafters, beams and posts are indicated , and we also show gutters, downspouts, and any roof venting required for your home.
-
Notes and Details Page(s)
- Your home comes detailed to meet the requirements of the latest adopted version of the ‘International Residential Code’, and our notes and details pages outline all the elements applicable to the design of your home. Compliance with further standards may need to be incorporated into your plan set, depending the requirements of your building department — these are usually done locally.
