PLAN 124-402
Key Specs
2950
sq ft
3
Beds
3
Baths
2
Floors
3
Garages
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Dimension
Depth : 54'
Height : 22'
Width : 82'
Height : 22'
Width : 82'
Area
Bonus: 339 sq/ft height 8'
First Floor: 2950 sq/ft height 8'
Garage: 664 sq/ft height 8'
First Floor: 2950 sq/ft height 8'
Garage: 664 sq/ft height 8'
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 8'
Roof
Primary Pitch : 7:12
Roof Framing : Truss
Roof Load : 30
Roof Type : Shingle
Roof Framing : Truss
Roof Load : 30
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : brick/siding
Framing : 2"x6"
Framing : 2"x6"
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Walk In Pantry Cabinet Pantry
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Main Floor Laundry
Master Sitting Area
Play Flex Room
Family Room Keeping Room
Main Floor Laundry
Master Sitting Area
Play Flex Room
Garage Features
Oversized Garage
Side Entry Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Grill Deck Sundeck
Grill Deck Sundeck
More
Jack & Jill Bath
Wheelchair Adaptable
Wheelchair Adaptable
Rooms
Bedroom 2:
176 sq/ft width 15' 4" x depth 11' 6"
Bedroom 3:
126 sq/ft width 11' 6" x depth 11'
Bonus Room - Unfinished:
359 sq/ft width 24' 6" x depth 14' 8"
Dining Room:
160 sq/ft width 13' 2" x depth 12' 2"
Family Room:
332 sq/ft width 18' 8" x depth 17' 10"
Garage:
653 sq/ft width 21' 8" x depth 30' 2"
Living Room:
235 sq/ft width 14' x depth 16' 10"
Master Suite:
268 sq/ft width 17' 4" x depth 15' 6"
Nook:
70 sq/ft width 10' x depth 7'
Office:
315 sq/ft width 18' x depth 17' 6"
What's Included In This Plan Set
Please note, if ordering a PDF set, it is not-modifiable. The CAD set is best for making local modifications
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
- Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
- Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
- Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
- Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
- Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details. Foundation types vary; please call to confirm the foundation type of the plan you are interested in.
- Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
- Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc. Specific details such as fireplaces, stairways, decks, etc. Details are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
- Section: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation.
- Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
