PLAN 119-112

Home Plan - Colonial Exterior - Front Elevation Plan #119-112
Home Plan - Colonial Exterior - Rear Elevation Plan #119-112

Key Specs

sq ft





Select Plan Set Options

What's included?
NOW $1165.50
You save $129.50
(10% savings)
Sale ends soon!
Also order by phone: 1-888-447-1946
Cost-to-Build Estimates
Cost to Build Reports Only $19.99 for a Limited Time!
This report will provide you cost estimates based on location and building materials.
Questions about building your home?
Send me your Newsletter, too!
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-888-447-1946
Hours:  Mon-Fri, 9AM - 8:30PM (EST)

See our Terms & Conditions and Privacy Policy.

PLAN 119-112

Key Specs

sq ft





This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.

Plan Description

Elegance and efficiency are artfully combined to make everyday stylish and graceful. Rich in architectural details and classical design, this home is not like any other home of its size. Immediately upon entry, as a visitor sees the sweep of the staircase and the soaring two-story foyer, they realize this is no ordinary house. The flowing first floor arrangement provides for easy family living and for memorable entertaining and special occasions. The second floor includes a Master Suite with all the amenities of the most luxurious homes. The three other bedrooms are spacious and have either their own private bath or a shared bath.

Full Specs & Features

Depth : 40'
Height : 34'
Width : 66'
Basement Unfinished: 1438 sq/ft
First Floor: 1437 sq/ft
Garage: 494 sq/ft
Second Floor: 1559 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Main Ceiling : 9"
Upper Ceiling Ft : 8"
Primary Pitch : 12:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : 2"x4"
Bedroom Features
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Storage Area
Unfinished Future Space
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For Sloping Lot
Suited For View Lot
Outdoor Spaces
Jack & Jill Bath

3rd BR Closet:

16 sq/ft width 7' 7" x depth 2' 2"

Bathroom 2:

88 sq/ft width 9' 4" x depth 9' 6"

Bathroom 3:

88 sq/ft width 9' 4" x depth 9' 6"

Bedroom 2:

170 sq/ft width 14' 2" x depth 12'

Bedroom 2 Closet:

13 sq/ft width 6' x depth 2' 2"

Bedroom 3:

181 sq/ft width 14' 6" x depth 12' 6"

Bedroom 3 Closet:

13 sq/ft width 6' x depth 2' 2"

Bedroom 4:

171 sq/ft width 12' 7" x depth 13' 8"

Bedroom 4 Closet:

16 sq/ft width 7' 2" x depth 2' 4"

Breakfast Room:

162 sq/ft width 12' 6" x depth 13'

Dining Room:

190 sq/ft width 12' 8" x depth 15'


197 sq/ft width 10' 8" x depth 18' 6"


458 sq/ft width 21' 6" x depth 21' 4"

Gathering Room:

205 sq/ft width 20' 2" x depth 10' 2"


186 sq/ft width 14' 4" x depth 13'

Laundry Room:

57 sq/ft width 6' x depth 9' 6"

Living Room:

181 sq/ft width 14' 6" x depth 12' 6"

Master Bathroom:

300 sq/ft width 19' 2" x depth 15' 8"

Master Bedroom:

373 sq/ft width 20' 10" x depth 17' 11"

Master Closet:

91 sq/ft width 12' 6" x depth 7' 4"

What's Included In This Plan Set

  • Cover Sheet: The cover sheet features an elevation of the home, sheet number index for the plan, and contact information.
  • Foundation: These drawings will detail and illustrate the foundation of the home, exterior and interior footings to support the floors and structure above. If a basement is purchased, it will show the stairs, bearing walls, and basement windows and doors.
  • First Floor Plan: This page is drawn to ¼”=1’-0” scale and includes exterior dimensions to build the home. The notes are precise directions for your builder. Important features such as built-ins, niches, and appliances are noted. Doors and windows are identified and specific sizing can be found on window and door schedules. *Framing is not included.
  • Second Floor Plan: The second floor includes stair details. Often the reflective roof detail is shown legibly over the second floor plan. This is helpful for the framing contractor. *Framing is not included.
  • Lighting and Electrical: On this sheet you have a schematic of the lights, electrical plugs, phone location, and code items such as smoke detectors. It is common place to build with your builder and/or electrician before the work starts to review this plan. Careful planning can make your home special and convenient for your family.
  • Second Floor Lighting: The same details as provided for the first floor.
  • Front and Rear Elevations: The front and rear elevations may be on separate pages depending on the size of the house. This page comes with exterior dimensions and notes required to complete construction. This is where the windows, doors, and interior trim details are illustrated, as well as wall heights, roof pitches and ridge heights.
  • Right and Left Elevations: The right and left elevations provide the same details as the front and rear elevations.
  • Roof Plan: This drawing, usually at ¼”=1’-0” scale, will be a bird’s eye view of the home. It will show the ridges, hips, and valleys. This page will show a beautifully designed roof.*Framing is not included.
  • Cross-Sections: Sections are used to further describe any architectural intent necessary for the builder or framer. This drawing will illustrate important changes in the floor, ceiling, and roof heights.
  • Cabinet Elevations*: Cabinet elevations are provided with your plans, and like the electrical plan, they are mainly a guide for estimating purposes. Cabinets are an area that is easy to customize and your builder or cabinet maker will work with you early on in the process to ensure that the correct cabinets are specified. Archival Designs believes cabinets should reflect your taste and budget. After framing and sheet rock installation sizes of walls may change slightly. The cabinet maker must take as built measurements to properly size your cabinets. **NOTE: The majority of house plans will include cabinet elevations in construction set; however, not all will include.
  • General Notes: Separate sheets that provide standard construction notes, in addition included are the details required to comply with International Residential Code (IRC) & Southern Building Code (SBC).
