PLAN 124-668
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 63'
Height : 25' 8"
Width : 80'
Area
Bonus: 121 sq/ft
First Floor: 2522 sq/ft height 9'
Garage: 1015 sq/ft height 9'
Second Floor: 679 sq/ft height 9'
Ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 7:12
Roof Framing : Truss
Roof Load : 25
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : siding/stone
Framing : 2"x6"
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Hobby Rec Room Game Room
Main Floor Laundry
Master Sitting Area
Mud Room
Storage Area
Workshop
Garage Features
Front Entry Garage
Oversized Garage
Lot Characteristics
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
More
Empty Nester
Rooms
Bathroom 2:
55 sq/ft width 5' x depth 11'
Bathroom 3:
72 sq/ft width 6' x depth 12'
Bedroom 2:
147 sq/ft width 12' 8" x depth 11' 8"
Bedroom 3:
164 sq/ft width 12' x depth 13' 8"
Breakfast Room:
174 sq/ft width 14' 6" x depth 12'
Den:
151 sq/ft width 13' x depth 11' 8"
Game Room:
513 sq/ft width 20' x depth 25' 8"
Garage:
698 sq/ft width 33' x depth 21' 2"
Garage Storage:
304 sq/ft width 22' 10" x depth 13' 4"
Gathering Room:
330 sq/ft width 16' x depth 20' 8"
Kitchen:
207 sq/ft width 14' 10" x depth 14'
Laundry Room:
77 sq/ft width 11' 8" x depth 6' 8"
Master Bathroom:
126 sq/ft width 10' 8" x depth 11' 10"
Master Bedroom:
240 sq/ft width 15' x depth 16'
Storage:
106 sq/ft width 16' 4" x depth 6' 6"
What's Included In This Plan Set
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
- Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
- Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
- Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
- Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
- Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details. Foundation types vary; please call to confirm the foundation type of the plan you are interested in.
- Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
- Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc. Specific details such as fireplaces, stairways, decks, etc. Details are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
- Section: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation.
- Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
Plan Set
$1500.00
$1825.00
$2875.00
$3150.00
$3450.00
$1200.00
Foundation
$0.00
$715.00
Framing
$0.00
$580.00
Additional Options
$465.00
$70.00
$1095.00
$165.00
$39.00
$165.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
