PLAN 1019-16

Home > Style > Traditional

Key Specs

3213
sq ft

4
Beds

3.5
Baths

1
Floors

3
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.

Modify This Plan

Plan Description

Hot tips can payoff when you trust the source. Knowing what to buy and when to buy it is a sign of prudence, patience and research. This plan is a sure bet. It appeals to a broad market and the efficient design is neatly wrapped in a non-wasteful package. Inside, the spaces flow effortlessly from one area to another and offer the feeling of a much larger home. The roof is clean and simple, yet the elevation is articulated enough for that must-have curb appeal. Look at the facts, assess the information and invest with confidence, knowing that your homework will pay off.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Full Specs & Features

Dimension

Depth : 75'

Height : 23' 5"

Width : 70'

Area

First Floor: 3213 sq/ft

Garage: 699 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 6:12

Roof Framing : Truss

Roof Type : Composition

Exterior Wall Framing

Exterior Wall Finish : Stone/Stucco

Framing : Block

Bedroom Features

Formal Dining Room

Formal Living Room / Parlor

Walk In Closet

Kitchen Features

Breakfast Nook

Kitchen Island

Additional Room Features

Den Office Study Computer

Family Room Keeping Room

Main Floor Laundry

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

Rooms

Bedroom 2:

158 sq/ft width 12' x depth 13' 2"

Bedroom 3:

144 sq/ft width 12' x depth 12'

Bedroom 4:

152 sq/ft width 12' x depth 12' 8"

Breakfast:

113 sq/ft width 10' 8" x depth 10' 8"

Covered Porch:

201 sq/ft width 18' 4" x depth 11'

Dining Room:

164 sq/ft width 13' 8" x depth 12'

Family Room:

326 sq/ft width 16' 4" x depth 20'

Garage:

642 sq/ft width 29' 8" x depth 21' 8"

Kitchen:

231 sq/ft width 17' 10" x depth 13'

Library:

135 sq/ft width 11' x depth 12' 4"

Living Room:

252 sq/ft width 14' x depth 18'

Master Bathroom:

168 sq/ft width 16' 4" x depth 10' 4"

Master Suite:

273 sq/ft width 14' x depth 19' 6"

Master Walk-In Closet:

114 sq/ft width 9' 8" x depth 11' 10"

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.

Questions? Call 1-888-447-1946

Plan Set

Reproducible Set:
$1250.00

For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.

CAD Set:
$2000.00

For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Foundation

Slab:
$0.00

Ideal for level lot, single layer concrete poured directly on grade.

Framing

Block:
$0.00

Concrete Block Exterior Walls (Upper Levels may be wood-framed)

Additional Options

Audio Video Design:
$100.00

Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide:
$39.00

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design:
$200.00

Receive an overlay sheet with suggested placement of lighting fixtures.

Mirror Reversed Sets:
$750.00

A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
