Plan Description

Perfect for a sloping lot, this beautiful getaway home offers walls of windows in back to capture the view. On the main level, the great room opens to decks via French doors on two sides. The master suite includes a corner tub, large shower, and dual closets. A den near the back receives light through a lovely bay window. With the kitchen open to the great room and bright dining nook, it's easy to interact with family and friends while preparing meals. A super-spacious family room sits on the lower level, along with a sitting room, extra bedroom and bath, wet bar, and storage.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Lower Floor

Reverse

Full Specs & Features

Dimension

Depth : 65' 4"

Height : 19' 11"

Width : 65'

Area

Basement Living: 1652 sq/ft height 9'

First Floor: 1652 sq/ft

Garage: 524 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 7:12

Roof Framing : Truss

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Shingle/Siding

Framing : ICF (Insulated Concrete Forms)

Bedroom Features

Fireplace

Main Floor Master Bedroom

Split Bedrooms

Walk In Closet

Kitchen Features

Kitchenette Wet Bar

Additional Room Features

Den Office Study Computer

Family Room Keeping Room

Great Room Living Room

Main Floor Laundry

Mud Room

Open Floor Plan

Storage Area

Vaulted / Cathedral Ceilings

Garage Features

Front Entry Garage

Outdoor Spaces

Covered Front Porch

Deck

Wrap Around Porch

Rooms

Bedroom 2:

width 13' 8" x depth 13' 4"

Den/Office:

width 10' x depth 11' 2"

Family Room:

width 19' x depth 31' 5"

Foyer:

width 8' 8" x depth 13'

Garage:

524 sq/ft width 23' 4" x depth 21' 4"

Great Room:

width 19' x depth 18' 10"

Kitchen:

width 15' x depth 13' 10"

Kitchen:

width 15' x depth 13' 10"

Master Suite:

width 13' 8" x depth 16'

Mechanical Room:

width 13' 8" x depth 9' 6"

Sitting Area:

width 13' 8" x depth 18' 6"

Storage:

width 13' 8" x depth 12' 2"

What's Included In This Plan Set

See a sample plan set

Foundation Plan(s): Footing locations, foundation details, etc.
Floor Plan(s): Layout of floor plan, window/door schedule, interior and exterior dimensions
Exterior Elevations: Exterior on all four sides, siding notes, roof pitches, garage door heights, etc.
Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
Cross Section(s): Cut-through view of home. Shows foundation, insulation, wall construction, ceiling heights, etc.
Electrical Plan(s): Lighting, switches, electrical outlet placement throughout home.
Detail Sheet(s): Additional structural details included in most log and ICF plans. Important: design loads and weather conditions vary by region. As a result the size, spacing, and layout of all structural elements in this home design may need approval by a structural engineer or code official based on your specific site location.
Construction Notes / Detail(s): Referencing the entirety of the project.
Framing Detail(s): Location of supporting walls and beams. Location/spacing of floor joists, floor framing details. Layout of roof, roof framing details, truss/rafter locations, connection details etc. If included, the framing layout is intended to be a suggested layout only. Design loads and weather conditions vary by region. As a result the size, spacing, and layout of all structural elements in this home design may need approval by a structural engineer or code official based on your specific site location.

Questions? Call 1-888-447-1946

Plan Set

CAD Single Build:
$1270.75

For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

PDF Set:
$1270.75

PDF plan sets are best for fast electronic delivery and inexpensive local printing.

CAD Unlimited Build:
$1865.75

For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Foundation

Daylight Basement:
$0.00

Ideal for sloping lot, lower level of home partially underground.

Framing

Insulated Concrete Forms:
$0.00

ICF Block Exterior Walls (Upper Levels may be wood-framed)

Additional Options

Right-Reading Reverse:
$165.75

Choose this option to reverse your plans and to have the text and dimensions readable.

Audio Video Design:
$140.25

Receive an overlay sheet with suggested placement of audio and video components.

Comprehensive Material List:
$335.75

Construction Guide:
$33.15

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design:
$140.25

Receive an overlay sheet with suggested placement of lighting fixtures.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
