PLAN 417-757
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 89' 4"
Height : 32'
Width : 73' 4"
Area
Bonus: 459 sq/ft
First Floor: 3359 sq/ft height 12'
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Stone/Stucco
Framing : Block
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Den Office Study Computer
Hobby Rec Room Game Room
Loft
Main Floor Laundry
Garage Features
Side Entry Garage
Outdoor Spaces
Balcony
Covered Rear Porch
Rooms
3rd BR Closet:
13 sq/ft width 6' x depth 2' 4"
Bathroom 2:
39 sq/ft width 5' 4" x depth 7' 4"
Bathroom 3:
51 sq/ft width 5' 8" x depth 9'
Bedroom 2:
145 sq/ft width 13' x depth 11' 2"
Bedroom 2 Closet:
20 sq/ft width 9' x depth 2' 4"
Bedroom 3:
147 sq/ft width 13' x depth 11' 4"
Bedroom 3 Closet:
20 sq/ft width 9' x depth 2' 4"
Bedroom 4:
145 sq/ft width 11' 4" x depth 12' 10"
Bedroom 4 Closet:
18 sq/ft width 7' x depth 2' 8"
Bonus Room - Finished:
369 sq/ft width 21' 4" x depth 17' 4"
Breakfast Room:
92 sq/ft width 7' 8" x depth 12'
Den/Office or Bedroom 1:
201 sq/ft width 12' 4" x depth 16' 4"
Dining Room:
155 sq/ft width 11' 6" x depth 13' 6"
Foyer:
50 sq/ft width 8' x depth 6' 4"
Garage:
594 sq/ft width 27' x depth 22'
Gathering Room:
323 sq/ft width 19' x depth 17'
Kitchen:
232 sq/ft width 15' x depth 15' 6"
Laundry Room:
80 sq/ft width 12' x depth 6' 8"
Living Room:
276 sq/ft width 15' 8" x depth 17' 8"
Master Bathroom:
180 sq/ft width 10' x depth 18'
Master Bedroom:
374 sq/ft width 14' 8" x depth 25' 6"
Master Closet:
154 sq/ft width 11' x depth 14'
Porch - Rear:
261 sq/ft width 29' x depth 9'
Porch - Right:
127 sq/ft width 21' 4" x depth 6'
Powder Room:
33 sq/ft width 6' 2" x depth 5' 6"
Walk-In Closet:
31 sq/ft width 6' x depth 5' 4"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1105.00
$1275.00
$1402.50
$2210.00
$595.00
Foundation
$0.00
Framing
$0.00
Additional Options
$42.50
$85.00
$33.15
$170.00
$25.50
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
