PLAN 117-835
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Dimension
Depth : 41'
Height : 30'
Width : 69' 2"
Height : 30'
Width : 69' 2"
Area
Basement Living: 1216 sq/ft
First Floor: 1701 sq/ft height 9'
Garage: 630 sq/ft
Second Floor: 1639 sq/ft height 9'
First Floor: 1701 sq/ft height 9'
Garage: 630 sq/ft
Second Floor: 1639 sq/ft height 9'
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 12:12
Roof Framing : Truss
Roof Type : Shingle
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x6
Framing : Wood - 2x6
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Guest Suite
Upstairs Master Bedrooms
Walk In Closet
Formal Dining Room
Formal Living Room / Parlor
Guest Suite
Upstairs Master Bedrooms
Walk In Closet
Additional Room Features
Family Room Keeping Room
Hobby Rec Room Game Room
Main Floor Laundry
Media Room
Mud Room
Storage Area
Upstairs Laundry
Workshop
Hobby Rec Room Game Room
Main Floor Laundry
Media Room
Mud Room
Storage Area
Upstairs Laundry
Workshop
Garage Features
Front Entry Garage
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Covered Rear Porch
Rooms
Bedroom 2:
width 14' 4" x depth 12' 6"
Bedroom 3:
width 14' 4" x depth 11'
Bedroom 4:
width 12' x depth 16'
Bedroom 5:
width 1' x depth 5' 1"
Dinette:
width 12' x depth 11'
Dining:
width 12' x depth 12'
Family Room:
width 14' x depth 14' 8"
Kitchen:
width 12' x depth 13' 8"
Living Room:
width 13' x depth 16'
Master Bedroom:
width 13' x depth 20'
Mother-In-Law Suite:
width 15' 2" x depth 14'
Rec. Room:
width 25' 3" x depth 14' 6"
Storage:
width 17' x depth 6' 6"
Theater:
width 13' x depth 16'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
