PLAN 453-547
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 77' 11"
Width : 106' 8"
Area
Basement Living: 1645 sq/ft height 10'
First Floor: 2945 sq/ft height 10'
Garage: 1377 sq/ft height 10'
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchenette Wet Bar
Additional Room Features
Family Room Keeping Room
Vaulted / Cathedral Ceilings
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Rooms
Breakfast:
171 sq/ft width 13' 8" x depth 12' 7"
Dining Room:
233 sq/ft width 14' 2" x depth 16' 6"
Family Room:
375 sq/ft width 22' 6" x depth 16' 8"
Garage:
520 sq/ft width 23' 6" x depth 22' 2"
Garage Two:
379 sq/ft width 17' 6" x depth 21' 8"
Guest Suite 2:
173 sq/ft width 13' 4" x depth 13'
Guest Suite 3:
129 sq/ft width 9' 10" x depth 13' 2"
Kitchen:
180 sq/ft width 12' x depth 15'
Living Room:
205 sq/ft width 14' 4" x depth 14' 4"
Master Suite:
253 sq/ft width 15' 10" x depth 16'
Recreation Room:
630 sq/ft width 20' 4" x depth 31'
What's Included In This Plan Set
- Foundation Plan(s): Dimensioned and detailed foundation plan (type as listed on home plan description). Typical foundation details, wall sections, and cornice details necessary for construction.
- Floor Plan(s): Dimensioned and detailed floor plans
- Exterior Elevations: Views of the home from all four sides showing exterior materials, roof slope, ridge heights, siding and trim notes.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Building Section(s): Shows the relationship between different levels, wall heights, and the overall building volume. May include details like foundation, framing, insulation, and finishes.
- Electrical Plan(s): Separate electrical plan (may be shown on floor plans in some cases). Shows the location of lights, receptacles, switches, etc.
- Construction Notes / Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
- Framing Detail(s): Framing plans (framing may be shown on floor plans in some cases.) If included, the framing layout is intended to be a suggested layout only. Design loads and weather conditions vary by region. As a result the size, spacing, and layout of all structural elements in this home design may need approval by a structural engineer or code official based on your specific site location.
Plan Set
$1950.00
$1950.00
$3900.00
Foundation
$0.00
Framing
$0.00
Additional Options
$60.00
$165.00
$395.00
$39.00
$165.00
$50.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
