PLAN 417-444
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 92' 6"
Height : 37'
Width : 101' 4"
Area
Bonus: 1644 sq/ft
First Floor: 3631 sq/ft
Second Floor: 2195 sq/ft
Ceiling
Main Ceiling : 10'
Upper Ceiling Ft : 9'
Roof
Primary Pitch : 6:12
Roof Framing : Trusses
Roof Type : Tile
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : Concrete block
Insulation : Exterior R-5 - Ceiling R-19
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Loft
Master Sitting Area
Mud Room
Play Flex Room
Storage Area
Garage Features
Oversized Garage
Split Garage
Entryway
Friend S Entry
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Balcony
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
More
Jack & Jill Bath
Rooms
3rd BR Closet:
31 sq/ft width 10' x depth 3' 2"
Bathroom 3:
56 sq/ft width 10' x depth 5' 8"
Bathroom 4:
62 sq/ft width 11' x depth 5' 8"
Bedroom 2:
176 sq/ft width 14' 8" x depth 12'
Bedroom 3:
205 sq/ft width 14' 8" x depth 14'
Bedroom 4:
205 sq/ft width 14' x depth 14' 8"
Bedroom 4 Closet:
16 sq/ft width 6' x depth 2' 8"
Bedroom 5 Closet:
38 sq/ft width 6' 2" x depth 6' 2"
Bonus Room - Finished:
271 sq/ft width 14' 8" x depth 18' 6"
Breakfast Room:
74 sq/ft width 8' 4" x depth 9'
Den/Office or Bedroom 1:
225 sq/ft width 15' x depth 15'
Dining Room:
199 sq/ft width 13' 4" x depth 15'
Foyer:
101 sq/ft width 11' 4" x depth 9'
Game Room:
394 sq/ft width 24' 8" x depth 16'
Garage:
740 sq/ft width 30' x depth 24' 8"
Garage Two:
690 sq/ft width 28' x depth 24' 8"
Gathering Room:
434 sq/ft width 20' 8" x depth 21'
Kitchen:
296 sq/ft width 14' 4" x depth 20' 8"
Laundry Room:
99 sq/ft width 13' x depth 7' 8"
Living Room:
318 sq/ft width 16' 4" x depth 19' 6"
Master Bathroom:
191 sq/ft width 14' x depth 13' 8"
Master Bedroom:
407 sq/ft width 22' x depth 18' 6"
Master Closet:
109 sq/ft width 7' x depth 15' 8"
Master Closet Two:
90 sq/ft width 9' x depth 10'
Porch - Front:
112 sq/ft width 14' x depth 8'
Porch - Rear:
651 sq/ft width 42' x depth 15' 6"
Powder Room:
42 sq/ft width 7' x depth 6'
Storage:
41 sq/ft width 4' 10" x depth 8' 6"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$2300.00
$2500.00
$2650.00
$4600.00
$900.00
Foundation
$0.00
Additional Options
$50.00
$100.00
$39.00
$200.00
$30.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
