PLAN 429-364
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.Plan Description
Full Specs & Features
Height : 31'
Width : 50' 9"
Second Floor: 1006 sq/ft height 8'
Roof Framing : Conventional
Roof Type : Shingle
Framing : Wood - 2x4
Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom
Walk In Closet
Main Floor Laundry
Open Floor Plan
Vaulted / Cathedral Ceilings
Deck
Bathroom 2:
51 sq/ft width 9' 9" x depth 5' 3"
Bathroom 3:
64 sq/ft width 12' 3" x depth 5' 3"
Bedroom 2:
156 sq/ft width 12' x depth 13'
Bedroom 2 Closet:
36 sq/ft width 7' 9" x depth 4' 9"
Bedroom 3:
156 sq/ft width 13' x depth 12'
Bedroom 3 Closet:
15 sq/ft width 2' 3" x depth 7'
Bedroom 4:
159 sq/ft width 12' x depth 13' 3"
Bedroom 4 Closet:
26 sq/ft width 4' 9" x depth 5' 6"
Breakfast Room:
109 sq/ft width 11' 3" x depth 9' 9"
Butler's Pantry:
27 sq/ft width 5' 3" x depth 5' 3"
Coat Closet:
7 sq/ft width 3' x depth 2' 6"
Deck:
195 sq/ft width 17' x depth 11' 6"
Dining Room:
250 sq/ft width 14' 9" x depth 17'
Family Room:
292 sq/ft width 19' 6" x depth 15'
Foyer:
56 sq/ft width 6' 3" x depth 9'
Garage:
489 sq/ft width 22' 6" x depth 21' 9"
Garage Storage:
54 sq/ft width 8' 9" x depth 6' 3"
Kitchen:
151 sq/ft width 11' x depth 13' 9"
Laundry Room:
65 sq/ft width 8' 6" x depth 7' 9"
Living Room:
178 sq/ft width 12' 6" x depth 14' 3"
Loft:
120 sq/ft width 11' 3" x depth 10' 9"
Master Bathroom:
185 sq/ft width 11' 9" x depth 15' 9"
Master Bedroom:
261 sq/ft width 14' 9" x depth 17' 9"
Master Closet:
48 sq/ft width 6' 3" x depth 7' 9"
Master Closet Two:
40 sq/ft width 5' 3" x depth 7' 9"
Pantry:
8 sq/ft width 2' 3" x depth 3' 9"
Porch - Front:
81 sq/ft width 14' 9" x depth 5' 6"
Powder Room:
29 sq/ft width 4' x depth 7' 3"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
| 5 Copy Set : $900.00 |
5 printed plan sets mailed to you. |
| 8 Copy Set : $1000.00 |
8 printed plan sets mailed to you. |
| PDF Set : $1250.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| Reproducible Set : $1250.00 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
| Single Set : $800.00 |
One printed set for bidding purposes only. Not a legal building set for construction. |
Foundation
| Daylight Basement: $0.00 |
Ideal for sloping lot, lower level of home partially underground. |
| Crawlspace: $150.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
| Slab: $150.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Framing
| Wood 2x4: $0.00 |
Wood 2x4 |
Additional Options
| Additional Construction Sets : $65.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design : $100.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
| Mirror Reversed Sets : $85.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
