Full Specs & Features
Depth : 38'
Height : 21'
Width : 80'
Garage : 1235 sq/ft
Main Floor : 1805 sq/ft
Patios : 480 sq/ft
Porch : 180 sq/ft
Ceiling Details : Vaulted ceiling through the Great Room, Kitchen & Dining areas.
Garage Ceiling : 11'
Main Ceiling : 9'
Primary Pitch : 7/12
Roof Framing : Pre-engineered trusses
Roof Load : Per local code requirements
Roof Type : Per Manufacturer
Exterior Wall Framing
Exterior Wall Finish : Per Owner/Builder
Framing : 2x6 Framing
Insulation : Per local code requirements
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Main Floor Laundry
Side Entry Garage
Jack & Jill Bath
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
